Chocogrind 110V
In stock
Features
upto 80 hours continuous running
Specially designed 150W motor with high heat resistant Class H insulation.
Upto 99 hours preset timer
Auto switch-off at the end of preset time.(Preset time can be changed in intervals of ± 1 hour).
capacity
Minimum of 700g and maximum of 2kg.(Tested with roasted cocoa nibs and sugar in a ratio of 70:30).
End of cycle buzzer
Beep alert at the end of set time.
Aisi 304 food grade stainless steel drum
Rust-resistant food grade stainless steel drum for healthy chocolates.
Patented conical stones
Grinding fineness is achieved faster.
Auto-shut off and auto-resume
The grinder will auto-shut off at 135° C motor coil temperature and will auto-resume once motor coil cools down to 100° C and hence ensures motor safety.
1 year warranty
Valid in the country of purchase.
Specifications
Form | Table Top |
Capacity (min) | 700g (tested for roasted cocoa nibs:sugar ratio of 70:30) |
Capacity (max) | 2kg (tested for roasted cocoa nibs:sugar ratio of 70:30) |
Voltage | 110V, 60Hz |
Motor Wattage | 150 watts |
Motor insulation | Class H |
Auto motor shut off and automatic resume | Motor automatically shuts off at 135° C motor coil temperature and automatically resumes once motor coil cools down to 100°C |
Grinding Stones | Conical |
Continuous maximum running time (for crushing, grinding and conching) | Tested upto 80 hours |
Automatic Timer | Preset time upto 99 hours (Can be changed in intervals of ± 1 hour) |
Buzzer | Automatic beep alert at the end of set time |
Drum | AISI 304 Food Grade Stainless Steel |
Shell | ABS |
Drum adapter material | POM(Delrin) - can withstand upto 110° C |
Stone axle cover material | POM(Delrin) - can withstand upto 110° C |
Wiper material | HDPE - can withstand upto 80° C |
Roller holder bottom bush material | POM(Delrin) - can withstand upto 110° C |
Roller stone spacer material | POM(Delrin) - can withstand upto 110° C |
Drum Shape | Dish-type |
Stone cleaner | Place the stone cleaner on the drum and the roller holder stone assembly on the stone cleaner. The cocoa mass on the stones can be wiped off into the drum by rotating the stones |
Power failure & resume safety protection | When power resumes after power cut, the grinder will not start automatically to ensure user safety. However the timer need not be reset. When ON button is pressed, grinder will run only for the remaining time |
Shock Proof | Yes |
Stone Assembly weight (in kg) | 2.9 |
Wire Cord Length (in mm) | 1650 |
Net weight (in kg) | 14.8 |
Gross Weight (in kg) | 16.5 |
Product Dimension (L*W*H in mm) | 460 x 272 x 288 |
Drum Size (Max Inner diameter * height in mm) | Ø250 X 180 |
Motor Speed in RPM (Rated load) | 1080 |
Drum Speed in RPM (without load) | 105 ± 5 |
Box Contents | Grinder unit, User Guide, Stone Cleaner,Spatula with extra spares: additional belt,wiper,motor capacitor,sleeve,housing,cover sleeve |
Product colour | Fortune white |
Lid colour | Purple |
Warranty | 1 Year |
Videos
FAQs
Ultra wet grinders are not designed to run continuously for long hours and hence they are not recommended for grinding cocoa nibs.
Yes, but we recommend that you buy an additional drum and stone assembly to avoid taste and flavour of one to affect the other when ground using the same drum & stone assembly. Please note that the timer function will not be useful for batter grinding as the minimum timer setting is more than batter grinding time.
No. The Ultra Chocogrind has not been tested for other applications.
Roasted cocoa nibs and sugar.
The Ultra Chocogrind has been tested only using roasted cocoa nibs.
Cocoa trees give cocoa beans. The husks of the cocoa beans are removed by roasting to get the roasted cocoa nibs.
Ultra Chocogrind has only been tested with roasted cocoa nibs, however you can also use cocoa powder.
No. We do not sell cocoa nibs.
You can buy roasted cocoa nibs from stores and websites online.
The Ultra Chocogrind is designed to grind roasted cocoa nibs and sugar. You can make chocolates of your choice with the cocoa mass.
It might. Please research recipes for the same.
The drum capacity is 2L
A minimum of 700 grams and a maximum of 2kg have been tested with 70:30 ratio of roasted cocoa nibs to sugar
The standard ratio of roasted cocoa nibs to sugar is 70:30. You can use the standard ratio or any other of your choice.
Sugar cubes should not be used. But you can use granulated sugar or powdered sugar (We recommend granulated white sugar).
Yes you can add white cane sugar as an alternative for sugar.
There is no standard time. Grinding fineness (micron size) and conching time will depend on your need. However we do not recommend continuous running beyond 80 hours.
There is no fixed minimum or maximum grinding time. Kindly refer to our product demonstration video for grinding procedure. You can also look up other resources for the same.
The timer can be preset to desired running time by pressing up/down arrow buttons, in intervals of 1 hour. After setting the time, you must press the ON/OFF button to start the grinder. In case you pause the grinder anytime, there is no need to reset the timer. When you restart the grinder, it will run only for remaining time.
The timer can be preset upto 99 hours
When power resumes after a power cut, grinder will not start by itself. This is for your own safety. This also ensures no damage to the grinder if cocoa mass solidifies over a long spell of power cut. However there is no need to reset timer. When you restart, the grinder will run only for the remaining duration.
The grinder has been tested in ambient household kitchen temperature. However please do not place it near any heat source including direct sunlight.
The Ultra Chocogrind’s motor is specially designed with high heat resistant class H insulation and hence it can run continuously for long hours. We have tested upto 80 hours continuous running.
The Ultra Chocogrind has been tested for upto 80 hours continuous running without any issues. The maximum withstanding temperature & material of plastics is given in the user guide. You can also refer to the specifications given in our website.
There is no need of any external fan to cool the motor as the Chocogrind motor is specially designed with high heat resistant class H insulation. You are however free to use one if you want to.
Yes
No. Roasted cocoa nibs have to be added little by little in small quantities.
No. Sugar has to be added little by little in small quantities.
Yes. We recommend you to crush before grinding.
The Ultra Chocogrind consumes 0.15 units of power per hour. Hence with 24-hours of continuous running, it will consume 3.6 units of power.
Yes. The grinder unit should be allowed to cool down for sometime before starting again for next batch chocolate making.
Yes you can add some nuts or dried fruits after you have transferred the cocoa mass into the mould or ice tray and then keep it in the fridge for cooling.
Yes you can.
You can only add milk in its powdered form.
Time is a function of quantity and quality of the roasted cocoa nibs used. During testing, 1kg of roasted cocoa nibs and sugar (in 70:30 ratio) took 9 hours to achieve a size of <20 micron. Hence the time taken might vary depending on grinding needs and procedures followed.
Conching as a practise is done to balance flavours. Hence the duration depends on the user’s preference.
As a practise tempering is done to get fat crystals together which gives chocolate a glossy look and snap. Tempering can be stopped at your preferred thickness & consistency of the cocoa mass.
No. Those have to be purchased from stores and websites online.
Tempering includes a step which requires cocoa mass to cool down. The granite/marble slab lends itself better to this step.
Yes, since the air conditioned environment helps to bring down the temperature of the cocoa mass to aid tempering.
No. It has to be purchased from stores and websites online.
Yes. Since the grinder runs continuously for long hours, heat can be felt on the drum and shell. However this does not impact the cocoa mass temperature.
The motor is tested for continuous running up to 80 hours. It also has a safety feature, that the grinder will auto shut off at 135° C motor coil temperature.
The stone cleaner is provided to wipe cocoa mass from the stones into the drum.
If the cocoa mass is left idle in the drum it can thicken. Do not restart the grinder immediately. The semi solid or fully solid cocoa in the drum should be melted using a hair dryer and spatula before restarting the grinder. Also ensure that no solid cocoa is sticking to the roller holder bottom bush. Refer our product maintenance video for procedure to melt the solidified cocoa.
Use warm water to clean the drum and roller holder stone assembly, every time after use. Wipe off with clean dry cloth. Liquid soap can also be used for cleaning.
Finished chocolates made out of roasted cocoa nibs and sugar have a shelf life of 12 months if stored in a refrigerator / chiller.
For 1 kg of roasted cocoa nibs and sugar ground, the cocoa mass output will be 850 to 900 grams. The number of chocolate bars will differ depending on size and shape of the mould used.
Warranty period is 1 year from date of purchase. Refer to the user guide for warranty policy
We provide spatula & stone cleaner as accessories along with the grinder.
Recipe
Recipes for 1kg as below:
70% Dark Chocolate
700 grams Roasted Cocoa Nibs
300 grams White sugar
64% Dark Chocolate with Fruits & Nuts
640 grams Roasted Cocoa Nibs
40 grams Cocoa Butter
320 grams White Sugar
40 grams Cranberry (to be sprinkled on top of the cocoa mass in the mould or ice tray before placing in the fridge)
40 grams Roasted Almonds (to be sprinkled on top of the cocoa mass in the mould or ice tray before placing in the fridge)
55% Dark Chocolate
550 grams Roasted Cocoa Nibs
350 grams White sugar
100 grams Cocoa Butter
Sugar Free Dark Chocolate
750 grams Roasted Cocoa Nibs
250 grams Sugar-free
100% Dark Chocolate
1000 grams Roasted Cocoa Nibs
